Roam Research MCP Server

A Model Context Protocol (MCP) server that provides comprehensive access to Roam Research's API functionality. This server enables AI assistants like Claude to interact with your Roam Research graph through a standardized interface. (A WORK-IN-PROGRESS, personal project not officially endorsed by Roam Research)

Installation

You can install the package globally:

npm install -g roam-research-mcp

Or clone the repository and build from source:

git clone https://github.com/2b3pro/roam-research-mcp.git
cd roam-research-mcp
npm install
npm run build

Features

The server provides powerful tools for interacting with Roam Research:

• Environment variable handling with .env support
• Comprehensive input validation
• Case-insensitive page title matching
• Recursive block reference resolution
• Markdown parsing and conversion
• Daily page integration
• Detailed debug logging
• Efficient batch operations
• Hierarchical outline creation

1. roam_fetch_page_by_title: Fetch and read a page's content by title, recursively resolving block references up to 4 levels deep
2. roam_create_page: Create new pages with optional content
3. roam_create_block: Create new blocks in a page (defaults to today's daily page)
4. roam_import_markdown: Import nested markdown content under specific blocks
5. roam_add_todo: Add multiple todo items to today's daily page with checkbox syntax
6. roam_create_outline: Create hierarchical outlines with proper nesting and structure
7. roam_search_block_refs: Search for block references within pages or across the graph
8. roam_search_hierarchy: Navigate and search through block parent-child relationships
9. roam_find_pages_modified_today: Find all pages that have been modified since midnight today
10. roam_search_by_text: Search for blocks containing specific text across all pages or within a specific page
11. roam_update_block: Update block content with direct text or pattern-based transformations
12. roam_search_by_date: Search for blocks and pages based on creation or modification dates
13. roam_search_for_tag: Search for blocks containing specific tags with optional filtering by nearby tags
14. roam_remember: Store and categorize memories or information with automatic tagging
15. roam_recall: Recall memories of blocks marked with tag MEMORIES_TAG (see below) or blocks on page title of the same name
16. roam_datomic_query: Execute custom Datalog queries on the Roam graph for advanced data retrieval and analysis

Setup

1. Create a Roam Research API token:

   • Go to your graph settings
   • Navigate to the "API tokens" section (Settings > "Graph" tab > "API Tokens" section and click on the "+ New API Token" button)
   • Create a new token

2. Configure the environment variables: You have two options for configuring the required environment variables:

   Option 1: Using a .env file (Recommended for development) Create a .env file in the roam-research directory:

   ROAM_API_TOKEN=your-api-token
   ROAM_GRAPH_NAME=your-graph-name
   MEMORIES_TAG='#[[LLM/Memories]]'


   Option 2: Using MCP settings (Alternative method) Add the configuration to your MCP settings file:

   • For Cline (~/Library/Application Support/Code/User/globalStorage/saoudrizwan.claude-dev/settings/cline_mcp_settings.json):
   • For Claude desktop app (~/Library/Application Support/Claude/claude_desktop_config.json):

   {
     "mcpServers": {
       "roam-research": {
         "command": "node",
         "args": ["/path/to/roam-research-mcp/build/index.js"],
         "env": {
           "ROAM_API_TOKEN": "your-api-token",
           "ROAM_GRAPH_NAME": "your-graph-name",
           "MEMORIES_TAG": "#[[LLM/Memories]]"
         }
       }
     }
   }


   Note: The server will first try to load from .env file, then fall back to environment variables from MCP settings.

3. Build the server (make sure you're in the root directory of the MCP):

   cd roam-research-mcp
   npm install
   npm run build


Usage

Fetch Page By Title

Fetch and read a page's content with resolved block references:

use_mcp_tool roam-research roam_fetch_page_by_title {
  "title": "Example Page"
}

Returns the page content as markdown with:

• Complete hierarchical structure
• Block references recursively resolved (up to 4 levels deep)
• Proper indentation for nesting levels
• Full markdown formatting

Create Page

Create a new page with optional content:

use_mcp_tool roam-research roam_create_page {
  "title": "New Page",
  "content": "Initial content for the page"
}

Returns the created page's UID on success.

Create Block

Add a new block to a page (defaults to today's daily page if neither page_uid nor title provided):

use_mcp_tool roam-research roam_create_block {
  "content": "Block content",
  "page_uid": "optional-target-page-uid",
  "title": "optional-target-page-title"
}

You can specify either:

• page_uid: Direct reference to target page
• title: Name of target page (will be created if it doesn't exist)
• Neither: Block will be added to today's daily page

Returns:

{
  "success": true,
  "block_uid": "created-block-uid",
  "parent_uid": "parent-page-uid"
}

Create Outline

Create a hierarchical outline with proper nesting and structure:

use_mcp_tool roam-research roam_create_outline {
  "outline": [
    {
      "text": "I. Top Level",
      "level": 1
    },
    {
      "text": "A. Second Level",
      "level": 2
    },
    {
      "text": "1. Third Level",
      "level": 3
    }
  ],
  "page_title_uid": "optional-target-page",
  "block_text_uid": "optional-header-text"
}

Features:

• Create complex outlines with up to 10 levels of nesting
• Validate outline structure and content
• Maintain proper parent-child relationships
• Optional header block for the outline
• Defaults to today's daily page if no page specified
• Efficient batch operations for creating blocks

Parameters:

• outline: Array of outline items, each with:
  • text: Content of the outline item (required)
  • level: Nesting level (1-10, required)
• page_title_uid: Target page title or UID (optional, defaults to today's page)
• block_text_uid: Header text for the outline (optional)

Returns:

{
  "success": true,
  "page_uid": "target-page-uid",
  "parent_uid": "header-block-uid",
  "created_uids": ["uid1", "uid2", ...]
}

Add Todo Items

Add one or more todo items to today's daily page:

use_mcp_tool roam-research roam_add_todo {
  "todos": [
    "First todo item",
    "Second todo item",
    "Third todo item"
  ]
}

Features:

• Adds todos with Roam checkbox syntax ({{TODO}} todo text)
• Supports adding multiple todos in a single operation
• Uses batch actions for efficiency when adding >10 todos
• Automatically creates today's page if it doesn't exist
• Adds todos as top-level blocks in sequential order

Import Nested Markdown

Import nested markdown content under a specific block:

use_mcp_tool roam-research roam_import_markdown {
  "content": "- Item 1\n  - Subitem A\n  - Subitem B\n- Item 2",
  "page_uid": "optional-page-uid",
  "page_title": "optional-page-title",
  "parent_uid": "optional-parent-block-uid",
  "parent_string": "optional-exact-block-content",
  "order": "first"
}

Features:

• Import content under specific blocks:
  • Find parent block by UID or exact string match
  • Locate blocks within specific pages by title or UID
  • Defaults to today's page if no page specified
• Control content placement:
  • Add as first or last child of parent block
  • Preserve hierarchical structure
  • Efficient batch operations for nested content
• Comprehensive return value:

  {
    "success": true,
    "page_uid": "target-page-uid",
    "parent_uid": "parent-block-uid",
    "created_uids": ["uid1", "uid2", ...]
  }


Parameters:

• content: Nested markdown content to import
• page_uid: UID of the page containing the parent block
• page_title: Title of the page containing the parent block (ignored if page_uid provided)
• parent_uid: UID of the parent block to add content under
• parent_string: Exact string content of the parent block (must provide either page_uid or page_title)
• order: Where to add the content ("first" or "last", defaults to "first")

Search Block References

Search for block references within pages or across the entire graph:

use_mcp_tool roam-research roam_search_block_refs {
  "block_uid": "optional-block-uid",
  "page_title_uid": "optional-page-title-or-uid"
}

Features:

• Find all references to a specific block
• Search for any block references within a page
• Search across the entire graph
• Supports both direct and indirect references
• Includes block content and location context

Parameters:

• block_uid: UID of the block to find references to (optional)
• page_title_uid: Title or UID of the page to search in (optional)

Returns:

{
  "success": true,
  "matches": [
    {
      "block_uid": "referenced-block-uid",
      "content": "Block content with ((reference))",
      "page_title": "Page containing reference"
    }
  ],
  "message": "Found N block(s) referencing..."
}

Search By Text

Search for blocks containing specific text across all pages or within a specific page:

use_mcp_tool roam-research roam_search_by_text {
  "text": "search text",
  "page_title_uid": "optional-page-title-or-uid",
  "case_sensitive": true
}

Features:

• Search for any text across all blocks in the graph
• Optional page-scoped search
• Case-sensitive or case-insensitive search
• Returns block content with page context
• Efficient text matching using Datalog queries

Parameters:

• text: The text to search for (required)
• page_title_uid: Title or UID of the page to search in (optional)
• case_sensitive: Whether to perform a case-sensitive search (optional, default: true to match Roam's native behavior)

Returns:

{
  "success": true,
  "matches": [
    {
      "block_uid": "matching-block-uid",
      "content": "Block content containing search text",
      "page_title": "Page containing block"
    }
  ],
  "message": "Found N block(s) containing \"search text\""
}

Update Block Content

Update a block's content using either direct text replacement or pattern-based transformations:

use_mcp_tool roam-research roam_update_block {
  "block_uid": "target-block-uid",
  "content": "New block content"
}

Or use pattern-based transformation:

use_mcp_tool roam-research roam_update_block {
  "block_uid": "target-block-uid",
  "transform_pattern": {
    "find": "\\bPython\\b",
    "replace": "[[Python]]",
    "global": true
  }
}

Features:

• Two update modes:
  • Direct content replacement
  • Pattern-based transformation using regex
• Verify block existence before updating
• Return updated content in response
• Support for global or single-match replacements
• Preserve block relationships and metadata

Parameters:

• block_uid: UID of the block to update (required)
• content: New content for the block (if using direct replacement)
• transform_pattern: Pattern for transforming existing content:
  • find: Text or regex pattern to find
  • replace: Text to replace with
  • global: Whether to replace all occurrences (default: true)

Returns:

{
  "success": true,
  "content": "Updated block content"
}

Search For Tags

Search for blocks containing specific tags with optional filtering by nearby tags:

use_mcp_tool roam-research roam_search_for_tag {
  "primary_tag": "Project/Tasks",
  "page_title_uid": "optional-page-title-or-uid",
  "near_tag": "optional-secondary-tag",
  "case_sensitive": true
}

Features:

• Search for blocks containing specific tags
• Optional filtering by presence of another tag
• Page-scoped or graph-wide search
• Case-sensitive or case-insensitive search
• Returns block content with page context
• Efficient tag matching using Datalog queries

Parameters:

• primary_tag: The main tag to search for (required)
• page_title_uid: Title or UID of the page to search in (optional)
• near_tag: Another tag to filter results by (optional)
• case_sensitive: Whether to perform case-sensitive search (optional, default: true to match Roam's native behavior)

Returns:

{
  "success": true,
  "matches": [
    {
      "block_uid": "matching-block-uid",
      "content": "Block content containing #[[primary_tag]]",
      "page_title": "Page containing block"
    }
  ],
  "message": "Found N block(s) referencing \"primary_tag\""
}

Remember Information

Store memories or important information with automatic tagging and categorization:

use_mcp_tool roam-research roam_remember {
  "memory": "Important information to remember",
  "categories": ["Work", "Project/Alpha"]
}

Features:

• Store information with #[[LLM/Memories]] tag
• Add optional category tags for organization
• Automatically adds to today's daily page
• Supports multiple categories per memory
• Easy retrieval using roam_search_for_tag
• Maintains chronological order of memories

Parameters:

• memory: The information to remember (required)
• categories: Optional array of categories to tag the memory with

Returns:

{
  "success": true,
  "block_uid": "created-block-uid",
  "content": "Memory content with tags"
}

Search By Date

Search for blocks and pages based on creation or modification dates:

use_mcp_tool roam-research roam_search_by_date {
  "start_date": "2025-01-01",
  "end_date": "2025-01-31",
  "type": "modified",
  "scope": "blocks",
  "include_content": true
}

Features:

• Search by creation date, modification date, or both
• Filter blocks, pages, or both
• Optional date range with start and end dates
• Include or exclude block/page content in results
• Sort results by timestamp
• Efficient date-based filtering using Datalog queries

Parameters:

• start_date: Start date in ISO format (YYYY-MM-DD) (required)
• end_date: End date in ISO format (YYYY-MM-DD) (optional)
• type: Whether to search by 'created', 'modified', or 'both' (required)
• scope: Whether to search 'blocks', 'pages', or 'both' (required)
• include_content: Whether to include the content of matching blocks/pages (optional, default: true)

Returns:

{
  "success": true,
  "matches": [
    {
      "uid": "block-or-page-uid",
      "type": "block",
      "time": 1704067200000,
      "content": "Block or page content",
      "page_title": "Page title (for blocks)"
    }
  ],
  "message": "Found N matches for the given date range and criteria"
}

Find Pages Modified Today

Find all pages that have been modified since midnight today:

use_mcp_tool roam-research roam_find_pages_modified_today {}

Features:

• Tracks all modifications made to pages since midnight
• Detects changes at any level in the block hierarchy
• Returns unique list of modified page titles
• Includes count of modified pages
• No parameters required

Returns:

{
  "success": true,
  "pages": ["Page 1", "Page 2"],
  "message": "Found 2 page(s) modified today"
}

Execute Datomic Queries

Execute custom Datalog queries on your Roam graph for advanced data retrieval and analysis:

use_mcp_tool roam-research roam_datomic_query {
  "query": "[:find (count ?p)\n :where [?p :node/title]]",
  "inputs": []
}

Features:

• Direct access to Roam's query engine
• Support for all Datalog query features:
  • Complex pattern matching
  • Aggregation functions (count, sum, max, min, avg, distinct)
  • String operations (includes?, starts-with?, ends-with?)
  • Logical operations (<, >, <=, >=, =, not=)
  • Rules for recursive queries
• Case-sensitive and case-insensitive search capabilities
• Efficient querying across the entire graph

Parameters:

• query: The Datalog query to execute (required)
• inputs: Optional array of input parameters for the query

Returns:

{
  "success": true,
  "matches": [
    {
      "content": "[result data]",
      "block_uid": "",
      "page_title": ""
    }
  ],
  "message": "Query executed successfully. Found N results."
}

Example Queries:

1. Count all pages:

[:find (count ?p)
 :where [?p :node/title]]

2. Case-insensitive text search:

[:find ?string ?title
 :where
 [?b :block/string ?string]
 [(clojure.string/lower-case ?string) ?lower]
 [(clojure.string/includes? ?lower "search term")]
 [?b :block/page ?p]
 [?p :node/title ?title]]

3. Find blocks modified after a date:

[:find ?block_ref ?string
 :in $ ?start_of_day
 :where
 [?b :edit/time ?time]
 [(> ?time ?start_of_day)]
 [?b :block/uid ?block_ref]
 [?b :block/string ?string]]

See Roam_Research_Datalog_Cheatsheet.md for more query examples and syntax documentation.

Search Block Hierarchy

Navigate and search through block parent-child relationships:

use_mcp_tool roam-research roam_search_hierarchy {
  "parent_uid": "optional-parent-block-uid",
  "child_uid": "optional-child-block-uid",
  "page_title_uid": "optional-page-title-or-uid",
  "max_depth": 3
}

Features:

• Search up or down the block hierarchy
• Find children of a specific block
• Find parents of a specific block
• Configure search depth (1-10 levels)
• Optional page scope filtering
• Includes depth information for each result

Parameters:

• parent_uid: UID of the block to find children of (required if searching down)
• child_uid: UID of the block to find parents of (required if searching up)
• page_title_uid: Title or UID of the page to search in (optional)
• max_depth: How many levels deep to search (optional, default: 1, max: 10)

Returns:

{
  "success": true,
  "matches": [
    {
      "block_uid": "related-block-uid",
      "content": "Block content",
      "depth": 2,
      "page_title": "Page containing block"
    }
  ],
  "message": "Found N block(s) as children/parents..."
}

Error Handling

The server provides comprehensive error handling for common scenarios:

• Configuration errors:
  • Missing API token or graph name
  • Invalid environment variables
• API errors:
  • Authentication failures
  • Invalid requests
  • Failed operations
• Tool-specific errors:
  • Page not found (with case-insensitive search)
  • Block not found by string match
  • Invalid markdown format
  • Missing required parameters
  • Invalid outline structure or content

Each error response includes:

• Standard MCP error code
• Detailed error message
• Suggestions for resolution when applicable

Development

Building

To build the server:

npm install
npm run build

This will:

1. Install all required dependencies
2. Compile TypeScript to JavaScript
3. Make the output file executable

You can also use npm run watch during development to automatically recompile when files change.

Testing with MCP Inspector

The MCP Inspector is a tool that helps test and debug MCP servers. To test the server:

# Inspect with npx:
npx @modelcontextprotocol/inspector node build/index.js

This will:

1. Start the server in inspector mode
2. Provide an interactive interface to:
   • List available tools and resources
   • Execute tools with custom parameters
   • View tool responses and error handling

License

MIT License
